Automatic N95/FFP2 Cup Mask Making Machine

  • Model:KS-C95P+V2
  • Brand:KINGSING
  • Capacity:18~20pcs/min
  • Voltage:220V 50Hz (Customizable)
  • Catalog:Download

This is the latest fully automatic N95 cup mask making machine, the cup shape can be customized, we can also copy the cup shape according to your cup mask samples. The cup mask hot press forming module can process 2 masks at a time, so as to maximize the efficiency of the entire line, it greatly improves the production efficiency. There are 2 head band installation methods for option: ultrasonic welding or staple fixing.

This machine integrates the functions of automatic material feeding, hot press forming, ultrasonic edge sealing, mask cutting, attaching nose clip, welding head strap, punching hole, welding breathing valve and so on. It adopts a 6-axis material prefeeder, and each axis is driven by an independent motor, which can ensure that the tension of the fabric is basically constant.

The breathing valves are fed by vibrating plate automatically, and the installation direction of the valve can be accurately controlled.

ModelValve FunctionMask PrintingValve Printing

Each function module can be closed freely in the program, for example, when you choose the machine with automatic installation of breathing valve, you can also close the valve function for the production of cup masks without exhalation valves.

Without ValveWith ValveWelding TypeStaple Type



Factory Overview:

Factory ExteriorFront Desk
Manufacturing EquipmentManufacturing Equipment
Customer With UsCustomer With Us

Company Certificate:

CE CertificateISO9001 CertificateTrademark Certificate



Demo Video:

Speed: 15~20pcs/min

Power Supply: 220V (Option: 380V, 415V, 110V)

Power consuption: 12KW

Air Pressure: 0.7Mpa (400L/min)

Net. Weight: 3000Kg

Raw Material List:

MaterialSpecificationWidthRoll IDRoll ODFor 1 Million
Surface Non-woven Fabric (Option)25~35g220mm55~80mm≤650mm1ton
Activated Carbon Fiber Cloth (Option)50~120g185mm55~80mm≤650mm4ton
BFE99 Melt Blown Fabric (2~3 layers)25~35g185mm55~80mm≤650mm1ton
Needle Punched Cotton150~220g220mm55~80mm≤650mm8ton
Flat Head Strap Elastic Rope5~7mm wide≤220mm18~30mm≤260mm800kg
Exhalation ValveVarious types for choice1 million
Nose Clip Wire With Melt Adhesive5mm wide≤150mm25~40mm≤260mm1ton
